Electric-Hospital-Bed SEGURO S

  • The GO button activates the bed, protecting patients from injury due to unintended movements, with the control system automatically locking after 3 minutes.
  • The designed guardrail ensures ample space and hand grips for patients to safely exit the bed, prioritizing high safety standards. lt features a two-step unlocking system to prevent accidental lowering of the guardrail (patented design).
  • When the backrest and thigh section are raised, the hospital bed’s patented design includes a dual retraction function of the bed surface.
Send Inquiry
Facebook Instagram Whatsapp

Electric-Hospital-Bed SEGURO S

  • The GO button activates the bed, protecting patients from injury due to unintended movements, with the control system automatically locking after 3 minutes.
  • The designed guardrail ensures ample space and hand grips for patients to safely exit the bed, prioritizing high safety standards. lt features a two-step unlocking system to prevent accidental lowering of the guardrail (patented design).
  • When the backrest and thigh section are raised, the hospital bed’s patented design includes a dual retraction function of the bed surface.
Facebook Twitter Youtube

DUAL RETRACTION PATENTED DESIGN INNOVATIVE 70+40 mm

Pressure ulcers, or bedsores, result from prolonged pressure and friction on skin and underlying tissues. -The dual retraction feature in a medical bed extends and distributes pressure evenly, reducing pressure concentration on the pelvic area. -This design enhances patient comfort and prevents pressure ulcer occurrence proactively. -The patented feature is applied to the backrest and thigh rest, retracting them by 70mm and 40mm respectively. -Retracting these components extends the bed surface in the pelvic area, aleviating pressure and shear forces, thus minimizing pressure ulcel risk -The innovative design prioritizes patient wel-being and offers a proactive solution for pressure ulcer prevention.

SOLID YET LIGHT MATTRESS PLATFORM

-5 pieces of removable blow moulded boards to minimise the slots where unwanted infections may hide. -With 2 pieces of 52*70mm plastic mattress retainers.

X-RAY EXAMINATION WITHOUT THE NEED TO MOVE THE PATIENT

Wide area of radio transparency. The Phenolic Resin Back Platform has an X-Ray cassette holder for chest x-ray examinations, without moving the patient and at any angle of the backrest. X-ray translucent mattress platform (Back section) with X-ray cassette (size 550*378mm).
Extemal Size (LxW)2150x1060 mm
Mattress Platform1925x880 mm
Safe Working Load250 kg
Height Adjustment390-840 mm
Back-Rest Adjustment0-75°(±10°)
Knee-Rest Adjustment0-33°(±10°)
Reverse Trendelenburg0-17°(±2°)
Trendelenburg0-17°(士2°)
Angle Indicator0-90°
Auto-Regression70+40 mm
Position Line30°
LINAK Motor4pcs
5" Double Side Castors, with three-grade caster pedal4pcs
PP Oasis Side Rail Extra Height, with nurse control panel1set
PP Oasis Bed Ends with Safe Lock1set
PP Bed Platform,Removable&Washable1set
X-ray Transparent Phenolic Resin Back Platform1pcs
Plastic SocketInside PP Guardrail for Phone or Glasses2pcs
PatentAngle Indicator For Back-rest And Trendelenburg Position4pcs
ф113mm Wall Bumper Wheel4pcs
IV Pole1set
IV Pole Prevision4pcs
Drainage Hook6pcs
Three-grade Central Locking Pedal2pcs
ABS Mattress Retainer2pcs
Nurse Controller1pcs
Hand Controller1pcs
Manual CPR1pcs
Electric CPR
Weighing System
Night Light
Bed Extension 200mm
Trapeze Socket
Back Up Battery
Fifth and Sixth Siderails

Description

BACKREST 30-DEGREESMART STOP

Backrest 30-degree smart stop: The clinically recommended position for preventing respiratory complications. Research shows that the 30-degree position significantly reduces the risk of lung infections.

EASY OPERATION USING THECONTROL PANEL

The “Light” version control panel, integrated into the head-side guardrail, is designed for easy reach and visibility. Positioned at the patient’s eye level, it allows intuitive bed adjustments—even for those with cognitive impairments—promoting greater comfort and independence.

HAND CONTROLLER AND NUSE CONTROLLER

Satellite control panel for nurses and hand controller for both patients and nurses feature ergonomic designs for comfortable use. The flexible spiral cable allows easy mobility and operation in an optimal position, enabling nurses to control all standard functions and automatic chair positioning with ease.

QUICK EMERGENCY ADJUSTMENTS

The medical bed is equipped with multiple emergency features to ensure rapid response in critical situations. Orange emergency buttons on the outer side of the "light" version control panel allow staff to act swiftly without diverting attention from the patient. A mechanical emergency lever under the mattress base enables quick CPR positioning, while the headboard and footboard can be easily removed without tools for better patient access. Additionally, a one-button emergency stop switch instantly halts all ongoing movements for enhanced safety.

MOVE THE PATIENT SAFELY AND EFFORTLESSLY

5" diameter central locking castors, three-position brake with directional function TPR tire, no worn-out after running 30kM, united forming without bolts.Pass Dynamic test: Bearing 120kg run 30KM and pass obstacles 500 time.1-speed unlock; 1-speed universal, 1-speed directional.

SAFE HYGIENE

No inaccessible recesses in the headboard or footboard and safety sides

PATIENT WEIGHT UNDER CONTROL AT ALL TIMES

The exclusive weighing system was designed to guarantee a high level of precision independently from the mattress platform's position.Thanks to the 4 sensors located at the corners of the bed, the load is better distributed and the reading level more accurate.The bed platform can be extended by 20 cm, providing added comfort for taller patients.
